| Nieuport 16 | ||
|---|---|---|
[[Image: |300px|]]
| ||
| Description | ||
| Role | Fighter aircraft | |
| Crew | one pilot | |
| Passengers | ||
| First flight | 1915 | |
| Entered service | 1916 | |
| Manufacturer | Societé Anonyme des Établissements Nieuport | |
| Produced | ||
| Dimensions | ||
| Length | 18 ft 6 in | 5.64 m |
| Wingspan | 24 ft 8 in | 7.52 m |
| Height | 7 ft 10 1/2 in | 2.40 m |
| Wing area | 143.16 sq ft | 13.30 sq m |
| Weights | ||
| Empty | 827 lb | 375 kg |
| Loaded | 1,213 lb | 550 kg |
| Maximum takeoff | ||
| Powerplant | ||
| Engine | 1 × Le Rhone-9Ja | |
| Power (each) | 110 horsepower | 82 kW |
| Performance | ||
| Maximum speed | 103 mph at sea level | 165 km/h at sea level |
| Cruising speed | ||
| Range | ||
| Ceiling | ||
| Rate of climb | 0 ft to 9,840 ft in 10.16 min | 0 m to 3,000 m in 10.16 min |
The Nieuport 16 was a French biplane fighter aircraft, which was used in World War I. It was designed and developed by Gustave Delage and Nieuport.
Development[edit | edit source]
The Nieuport 16 was developed from the Nieuport 11, with which it had many similarities. It was equipped with the more powerful 110 horsepower Le Rhóne 9J engine, as well ash wings of a greater wingspan than on the Nieuport 11, a combination that gave it superior flight performance.
The Nieuport 16 was armed with a Lewis machine gun mounted on the upper wing. With the introduction of synchronized machine guns, Vickers machine guns were mounted. To destroy airships, it was equipped with upwardly inclined, electrically fired Le-Prieur missiles, which were attached to the wing struts.[1]
References[edit | edit source]
- ↑ World Aircraft Information Files Aviation Partwork. Midsummer Books Ltd. File 902 Sheet 8 (A-Z of Aircraft:N - NH Industries NH-90 (continued) to Nieuport type 28)
